Process: 0.18 µm CMOS
|
|
Frequency: 266MHz
|
|
Core: I.I.F/M.F/M
|
|
Cache
|
16KB
|
|
4way 2port
|
|
Non Blocking (Data)
|
|
|
System Bus: Pipelined
|
|
Power Consumption
|
1.5W for core
|
|
2.0W for chip
|
|
|
Package: BGA352
|
|
Sample: Now
|
|
|
|
|
|
| Note: The use of Adobe's Acrobat Reader 4.0 is recommended to have all download
and
browsing
features
available
for
pdf
files.
|
|
 |
|
Package BGA-352P-M01
1 page, 50 KB
|
|
 |
|
