| MSP430C311s | 2K ROM | T/P, WDT, BT, T/C, LCD Driver | 48 SSOP | ||
| MSP430C312 | 4K ROM | T/P, WDT, BT, T/C, LCD Driver | 56 SSOP | ||
| MSP430C313 | 8K ROM | T/P, WDT, BT, T/C, LCD Driver | 56 SSOP | ||
| MSP430C314 | 12K ROM | T/P, WDT, BT, T/C, LCD Driver | 56 SSOP | ||
| MSP430C315 | 16K ROM | T/P, WDT, BT, T/C, LCD Driver | 56 SSOP | ||
| MSP430P313 | 8K OTP | T/P, WDT, BT, T/C, LCD Driver | 56 SSOP | ||
| MSP430P315 | 16K OTP | T/P, WDT, BT, T/C, LCD Driver | 56 SSOP | ||
| MSP430P315s | 16K OTP | T/P, WDT, BT, T/C, LCD Driver | 48 SSOP | ||
| MSP430C323 | 8K ROM | T/P, WDT, BT, T/C, LCD Driver, ADC | 64 QFP 64 TQFP 68 PLCC |
||
| MSP430C325 | 16K ROM | T/P, WDT, BT, T/C, LCD Driver, ADC | 64 QFP 64 TQFP 68 PLCC |
||
| MSP430P325 | 16K OTP | T/P, WDT, BT, T/C, LCD Driver, ADC | 64 QFP 64 TQFP 68 PLCC |
||
| MSP430C336 | 24K ROM | T/P, WDT, BT, T/C, LCD Driver, T_A, MPY, USART |
100 QFP | ||
| MSP430C337 | 32K ROM | T/P, WDT, BT, T/C, LCD Driver, T_A, MPY, USART |
100 QFP | ||
| MSP430P337 | 32K OTP | T/P, WDT, BT, T/C, LCD Driver, T_A, MPY, USART |
100 QFP |
Key To Peripherals In Device Chart
| ADC: | six-input channel, 14-bit analog-to-digital converter with integrated current source |
| T/P: | timer/port module for slope A/D conversions, two 8-bit, or a single 16-bit timer/counter |
| WDT: | 15-bit watchdog or interval timer |
| BT: | eight-bit general-purpose timer (for real timer clock generation) |
| MPY: | hardware multiplier |
| T_A: | 16-bit timer_A with five (5) capture/compare registers and five (5) outputs |
| USART: | UART/SPI module |
| T/C: | 8-bit timer counter capable of providing serial communications |
For ROM-coded devices, suggested resale pricing in quantities of 25,000 starts at $1.75. More information on the MSP430 family of devices is available on the World Wide Web at
http://www.ti.com/sc/docs/msp/msp430/msp430.htm
Trademark:
Windows is a registered trademark of Microsoft Corporation.
DALLAS (June 22, 1998) -- A microcontroller family from Texas Instruments (TI) that provides an ultra-low power solution is now available for the first time outside Europe. These devices offer a high-performance 16-bit reduced instruction set computing (RISC) microcontroller unit (MCU) and integrated peripherals for industry-leading MIPS/Watt performance. This combination is ideal for applications such as utility metering, industrial metering, high-precision portable measurement and home measurement such as thermostats and smoke detectors. Designed in extensively by utilities in Europe, these devices will be especially useful in North America for remote meter reading as utilities are deregulated.
The MSP430 device family is fully supported by a development tool set including a Windows® based software simulator, evaluation boards with assembler and linker, C-compiler with industry-leading efficiency, in-circuit emulators, UV-EPROM devices, programming adapter or gang programmer for OTP devices, and a JTAG tool set for debug.
