Highest-bandwidth low-voltage rail-to-rail CMOS op amp

– BiFET performance for single-supply systems

Product Features

The TLV2772 is a dual wide-bandwidth (4.9 MHz) CMOS operational amplifier. This amplifier offers the highest bandwidth and fastest slew rate (9 V/ms) of any low voltage single supply rail-to-rail CMOS amplifier.

The TLV2772 is a great solution for designs requiring the ac performance of BiFETs from a low-voltage single supply. It is ideal for driving analog-to-digital converters (ADCs).

For digital processing systems, the TLV2772 will operate from the same power supply and deliver the ac performance and rail-to-rail output drive analog-to-digital converters require. In addition, its ability to drive 600-Ω loads makes the TLV2772 a good choice for telecommunication applications.

The TLV2772 strengthens TI’s leadership position as a low-voltage single supply CMOS op amp provider.

For other applications that require rail-to-rail output without the high bandwidth and slew rate, consider the TLC2272 or TLV2442. The TLC2272 has the lowest noise floor in the industry and the TLV2442 offers superb common mode input range.

The TLV2772 is available in 8-pin packages: SOIC, MSOP, and PDIP.

• TLV2772ID
