Product Features

• Exceptional ac performance: 5.1-MHz bandwidth 10.5-V/µs slew rate
• Rail-to-rail output
• Low noise: 17 nV/
• Low input offset voltage: 360 µV
• Complete family of singles, duals, and quads
• Characterized for operation from 0°C to 70°C and –40°C to 125°C

The TLV277x family provides the highest ac performance of any low-voltage single-supply CMOS operational amplifier. The 5.1-MHz bandwidth and 10.5-V/µs slew rate are suitable for applications previously requiring split-supply BiFETs and preamps for analog-to-digital converters. The low THD resulting from the high slew rate and 600- output drive makes the TLV277x well suited for telecom applications. Measurement, medical and industrial applications will benefit from the 360-µV offset voltage and 17-nV/ noise floor. These devices operate over a supply voltage range of 2.7 V to 5.5 V, and are fully specified at 3 V and 5 V. For designs that do not require the ac performance of the TLV277x family, consider the TLV24x2 or TLV246x family.

• TLV2771CD
• TLV2772CD
